New EASYKEY5 2023 – MOTORBIKE SMART KEY & IMMOBILIZER PROGRAMMER
มีอะไรใหม่ใน EASYKEY 5.0
• ฟังก์ชั่นสมาร์ทคีย์
– เพิ่มรถมอเตอร์ไซต์รุ่นใหม่เพิ่มเติมถึงปี 2023 สำหรับ HONDA, YAMAHA
– อัปเดตฟังก์ชันการลงทะเบียนคีย์ด่วนโดยการแก้ไขข้อมูลโดยตรง (ไม่จำเป็นต้องอ่าน KEYID จาก SCU) สำหรับรหัส SCU: K01| K29| K35| K36| K77| K96| K97| K0R| MKHD0| MKTD0| MKRD1…
– รองรับการรีแมปฟังก์ชัน OFF/ON SMART KEY (ชั้นความปลอดภัยที่ 2) ตัดระบบให้รถสตาร์ทได้โดยไม่มีกุญแจ สำหรับ HONDA ACG ECM
– เพิ่มประสิทธิภาพฟังก์ชั่นการอ่านและการเขียน KEYID, ECMID, โหลดข้อมูลตัวอย่างสำหรับ SCU ของ YAMAHA และ SUZUKI
• ฟังก์ชันอิมโมบิไเซอร์ สำหรับ VESPA
– เพิ่มโมเดลใหม่เพิ่มเติมสำหรับตลาดยุโรปและเอเชียด้วยรหัส ECM: PGU0X, PGT1X, PGR0X, PGQ16 (Medley), AC2I&5I, (MIU G4 กำลังอัปเดต) …
– อัปเดตฟังก์ชัน “รีเซ็ตเป็นใหม่” สำหรับรหัส ECM ใหม่: PGN0X, PGR0X, PGS0X, PGU0X, PGT1X, PGQ16…
• ฟังก์ชันมาตรวัดระยะทาง ปรับไมล์
เพิ่มรุ่นใหม่เพิ่มเติมถึงปี 2023 สำหรับ:
– HONDA: แอร์เบลด (2022-2023), SH (2022-2023), Beat (2017-2020), Dunk, Vario 150/160 (2021-2023), คลิก 150/160 (2021-2023), X-ADV 2018, FORZA, ตะกั่ว 2022, MSX 2019, โซนิค 2018-2020
– YAMAHA: แอร็อกซ์ (2021-2023), NVX (2021-2023), QBIX (2017-2019), GRAND FILANO, TMAX (2013), TMAX 2015
WHAT IS NEWER IN EASYKEY 5.0 UPDATE 30/08/2023
• SMART KEY FUNCTION
– Adding more new models up to 2023 for HONDA, YAMAHA
– Update quick key registration function by direct data edit (don’t need to read KEYID from SCU) for SCU codes:
K01| K29| K35| K36| K77| K96| K97| K0R| MKHD0| MKTD0| MKRD1…
– Support remap OFF/ON SMART KEY function (2nd security layer) for HONDA ACG ECM
– Optimize the function of reading and writing KEYID, ECMID, loading sample data for SCU of YAMAHA and SUZUKI
• IMMOBILISER FUNCTION
– Adding more new models for Europe and Asia market with ECM codes: PGU0X, PGT1X, PGR0X, PGQ16 (Medley), AC2I&5I, (MIU G4 is updating) …
– Updated “RESET TO NEW” function for new ECM codes: PGN0X, PGR0X, PGS0X, PGU0X, PGT1X, PGQ16…
• ODOMETER FUNCTION
Adding more new models up to 2023 for:
– HONDA: Air Blade (2022-2023), SH (2022-2023), Beat (2017-2020), Dunk, Vario 150/160 (2021-2023), Click 150/160 (2021-2023), X-ADV 2018, FORZA, LEAD 2022, MSX 2019, SONIC 2018-2020
– YAMAHA: Aerox (2021-2023), NVX (2021-2023), QBIX (2017-2019), GRAND FILANO, TMAX (2013), TMAX 2015
• NEW ACCESSORIES, HARDWARE & UTILITIES
– Additional data cables, converter accessories (optional) for enhanced functionality
– Software updates automatically, easily and remotely
ราคาเครื่องตาม Package แบ่งเป็น 8 เวอร์ชั่นดังนี้
1. EasyKey V5.0 Standard version ราคา 15,888บาท
2. EasyKey V5.0 Standard FULL ( +Easy Key Adapter + ODO Cables + OFF SMK Cable) ราคา 28,888บาท
3. EasyKey V5.0 TMA Version (add YamahaTMAX ) 23,888บาท
4. EasyKey V5.0 TMA Version FULL (add YamahaTMAX +Easy Key Adapter + ODO Cables + OFF SMK Cable) ราคา 36,888บาท
5. UPGRADE Package from STD toTMA ราคา 8,500บาท
6. Easy Key Adapter ราคา 8,000บาท
7. ODOMETER V5.0 ACCESSORY Cables 3,500บาท
8. OFF SMK & NEW IMMOBILIZER (ON/OFF Smart key and new Piaggio, Vespa immobilizer) 1,850บาท
• แถมฟรี: 01 year using copyright MOTODATA 7 software มูลค่า 1,750บาท
DTDAUTO UPDATE CENTER เป็นแอพพลิเคชั่นอัพเดตสำหรับอุปกรณ์ของ DTDAuto ปัจจุบันลูกค้าใช้โปรแกรมนี้เพื่ออัปเดตสำหรับ MOTOSCAN 7, MOTOBOX, EASYKEY การอัปเดตสำหรับอุปกรณ์อื่น ๆ จะได้รับการอัปเดตในครั้งต่อไป วิธีลงโปรแกรม DTD UPDATE CENTER
| STRUCTURE IMAGE OF EASYKEY 5.0 | |
|
|
| OPTION | FUNCTION |
| EASYKEY 5-STD OPTION Product code: ET17STD (standard package) |
1. SMART KEY FUNCTION FOR HONDA, YAMAHA, SUZUKI
– Read all KEYID# and ECMID directly from vehicle SCUs – Program all cases about Smart Key System such as add keys, lost all of keys, sync SCU-ECM: ON VEHICLE, ON SIMULATOR & Fast automatic programming direct to SCU & ECM (without vehicles) as following:: + Register more FOB# for all of cases + Register FOB# when lost all of the FOB# + Quick key registration with KEYID and PN (don’t need to read KEYID in SCU) for SCU types of codes: K01| K29| K35| K36| K77| K96| K97| K0R| MKHD0| MKTD0| MKRD1 + Delete KEYID in SCU memory + Synchronize SCU & ECM for all of cases + Write ECMID code into SCU (HONDA, YAMAHA, SUZUKI) + Inactivate FOB# code in SCU when lost FOB# + Check FOB# & SCU + Display the status of KEY (ON/OFF) + Display SCU information – Restore SCU data from sample data for HONDA, YAMAHA, and SUZUKI (this function is used to repair software inside SCU when SCU data is faulty) – Copy data from source SCU to destination SCU for all motorbikes that have Smart key system: HONDA, YAMAHA, SUZUKI (This function is used to repair, and swap SCU when SCU hardware/software faults) – Quick sync SCU & ECM (without FOB) for HONDA: SH, PCX, X-ADV… and equivalent vehicles2. KEY PROGRAMMING FUNCTION FOR PIAGGIO, VESPA – Read KEYID from IC/ ECM – RESET TO NEW immobilizer system – Register more keys for all cases – Register a new key when lost all of the keys – Check the current key via the antenna (for vehicles ECM: PGQ16) – Support to make key for Motorcycles with ECM codes: ACI100, ACI500 / ACI501 / ACI502 / ACI503 / ACI504 ACI600 / ACI601 / ACI602 / ACI603 / ACI604 / ACI605 / ACI606, ACII / AC2I / AC5I / AC8I / AC13I / AC21I / AC23I, AC19I / AC20I / AC27I, AC24I / AC25I / AC32I MIU1, MIU2, MIU4, MIU G3, RIU1, PGN04, PGS02, PGS05, PGS06, PGU0X*, PGT1X*, PGR0X*, PGQ16* (MEDLEY)…3. HONDA ON/OFF SMART KEY FUNCTION * (optional)4. ODO METER CORRECTION FUNCTION ** (optional)A gift MOTODATA software used to lookup motorbikes repair data on computer or mobile for 01 year (Note: If you want to continue using for the next time then pay the renewal fee. Renewal fee is 50 $US for next year) |
| EASYKEY 5-TMA OPTION Product code: ET17TMA (additional support for YAMAHA TMAX 2017-2020) |
– Include all functions of the EASYKEY STD option
– Add key programming for YAMAHA TMAX (2017-2020) + Register more FOB + Register FOB# when lost all of the FOB# + Inactivate/Activate FOB# in SCU + Read KEYID# in SCU + Delete KEYID# in SCU memory + Copy SCU data + Check KEYID + Check FOB & SCU (Note: STD version is not supported YAMAHA TMAX, If you want to use this function then you upgrade from STD version with an additional fee) A gift MOTODATA software used to lookup motorbikes repair data on a computer or mobile for 01 year (Note: If you want to continue using for the next time then pay the renewal fee. Renewal fee is 50 $US for next year) |
| ODO FUNCTION OPTION Product code: EK07-ODO (optional) |
ODO value correction, restore original ODO data, read ODO value ** to repair ODO system for HONDA, YAMAHA, PIAGGIO, VESPA
Compatible vehicle ODO list:- HONDA: AIR BLADE (2013-2019), AIR BLADE (2020-2021), AIR BLADE (2022-2023), CB150R (2017-2019), CB300R (2017-2019), CB650R (2019-2021), CBR250, CBR650R (2019-2021), CB650F (2019-2021), CBR650F (2019-2021), CB500X (2019-2021), CBR500R (2019-2021), CB500F (2019-2021), CBR 50RR (2019-2021), CBR 150R (2019-2021), FUTURE NEO Fi, FUTURE X Fi, GENIO (2019-2021), LEAD (2013-2019), LEAD (2020-2021), LEAD (2022-2023), PCX (2008-2013), PCX (2014-2017), PCX 2018, PCX HYBRID, PCX 150 (2021), PCX 160 (2021), SH 300i, SH MODE (2013-2019), SH 125/150/125D/150D/SM (2013-2017), SH 125/150/125D/150D/SM (2018-2019), SH 125/150/125D/150D/SM (2020), SCOOPY-I (2017-2020), SCOOPY 2021, SUPER CUP 125 (2021-2021), MSX, GENIO (2019-2021), VISION 2021, VARIO 150, WINNER, WINNER X, X-ADV, DYLAN, ZOOMER X (2013-2017), ZOOMER X (2018-2020), SONIC, WAVE 110 2021, WAVE 125 (2003-2005), CLICK (2012-2014), CLICK (2014-2017) CLICK (2018-2020), VARIO (2014-2017), VARIO (2018-2020), BEAT (2020-2023), DUNK (2017-2023), SUPRA GTR 150 (2014-2018), FORZA, MSX 125 (2019-2020), SUPRA GTR 150 (2019-2023), CLICK (2021-2023), VARIO (2021-2023), X-ADV 2018- YAMAHA: ACRUZO , AEROX (2017-2019), AEROX (2020-2023), LEXI S, LATTE, FREGO, NVX (2017-2019), NVX (2020-2023), NMAX (2017-2020), NMAX (2021-2023), NMX (2017-2020), NMX (2021-2023), M-SLAZ (2016-2019), MT-03 (2015-2019), MT-15 (2016-2021), MT-25 (2015-2019), JANUS, TFX, EXCITER (2014-2018), EXCITER (2019-2020), FZ 150, FZ 150i, GRANDE, NOUVO SX, NOUVO LX, YZF-R3 (2014-2018), YZF-R25 (2014-2018), R15, XMAX 300 (2017-2018), TMAX (2001-2003), TMAX (2004-2007), TMAX (2008-2011), TMAX 500 (2008-2011), TMAX 2013, TMAX 2015, Grand Filano, QBIX, XMAX(2017-2019)- PIAGGIO: MEDLY 125, MEDLY 150, MEDLY 125 ABS, MEDLY 150 ABS, LIBERTY ABS, LIBERTY 125 3V PGN04, LIBERTY 150 3V PGN04, LIBERTY 125 3V PGT01, LIBERTY 150 3V PGT01, LIBERTY 125 3V PGS02, LIBERTY 150 3V PGS02, LIBERTY ABS PGS06- VESPA: PRIMAVE 125 PGN04, PRIMAVE 150 PGN04, SPRINT 125 3V PGN04, SPRINT 150 3V PGN04, SPRINT 125 3V PGT01, SPRINT 150 3V PGT01, SPRINT 125 3V PGS02, SPRINT 150 3V PGS02- SUZUKI: RAIDER (2017-2021), SATRIA (2017-2023), GSX 150R (2017-2023) |
| SMART KEY OFF & NEW IMMOBILISER FUNCTION OPTION Product code: EK07- OFF SMK (optional) |
1. SMART KEY FUNCTION (HONDA)
Support remap to OFF/ON SMART KEY (2nd layer of security) for HONDA ACG ECM2. SUPPORT NEW PIAGGIO/ VESPA MODELS UP TO 2023 – Support programming key for new models with ECM codes: PGU0X, PGT1X, PGR0X, PGQ16 (Medley), (MIU G4* is updating) … – Support the “RESET TO NEW” function for new ECM codes from PGN0X, PGR0X, PGS0X, PGU0X, PGT1X, PGQ16… |
|
IMPORTANT NOTES WHEN YOU ORDER:
1. To make a Smart key for TMAX YAMAHA, you need to buy EASYKEY 5-TMA model. Product code: “ET17TMA” 2. To support models and ECM code with the mark ‘*’, you need to buy more Easykey Adapter and cables of “OFF SMART KEY & NEW IMMOBILISER” function. Product code: “EK07- OFF SMK” 3. To support functions with the mark ‘**’, you need to buy more EASYKEY ADAPTER and cables of “ODO” function. Product code: “EK07-ODO” |
|
● STANDARD PACKAGE
| EASYKEY 5.0 STD (included in the package) |
||
|---|---|---|
| NO. | ITEM | IMAGE |
| 1 |
Handheld
|
 |
| 2 |
EK07-SP01 cable used to program smart key for HONDA: SH, PCX, X-ADV…
|
 |
| 3 |
EK07-VS02 cable used to program smart key for HONDA: VISION 2021, PCX 2021
|
 |
| 4 |
EK07-LV01 cable used to program smart key for HONDA: AIR BLADE, LEAD, VISION, VARIO, CLICK
|
 |
| 5 |
EK07-YS01 cable used to program smart key for YAMAHA, SUZUKI
|
 |
| 6 |
EK07-PG cable used to program smart key for PIAGGIO
|
 |
| 7 |
EK07-ACI cable used to program smart key for PIAGGIO
|
 |
| 8 |
Power cable
|
 |
| 9 |
220V/AC to 12V/DC power converter
|
 |
| 10 |
EK07-Update cable
|
 |
| 11 |
Quick guide
|
 |
| 12 |
Handbag
|
 |
|
Note: We are a manufacturer and all product information has been detailed, and accurate for each function, and each type of vehicle on the website. Customers need to read very carefully and take responsibility for themselves when buying online products. The Goods will be delivered to the customer as all the information we have posted. The refund is not accepted unless the goods are incorrect in the description.
|
||
● EXTRA PACKAGE
| TMAX SMART KEY CABLE OPTION (not included in price of standard EASYKEY package) |
||
|---|---|---|
| NO. | DESCRIPTION | IMAGE |
| 1 |
EK07-TM01 cable used to read KEYID for YAMAHA TMAX
|
 |
| 2 |
EK07-TM02 cable used to programming SCU for YAMAHA TMAX
|
 |
|
Note: use for EASYKEY TMA, EASYKEY STD is not supported. If you want to use this function then upgrade from STD version with additional fee
|
||
| OPTIONAL ACCESSORIES | ||
|---|---|---|
| NO. | DESCRIPTION | IMAGE |
| 1 |
EASYKEY adapter (product code: EK07-ADA)
|
 |
| 2 |
ODO value correction, restore original ODO data, read ODO value to repair ODO system for HONDA, YAMAHA, SUZUKI, PIAGGIO, VESPA (product code: EK07-ODO)
|
 |
| 3 |
Support remap to OFF/ON SMART KEY, support new PIAGGIO/ VESPA models up to 2023 (product code: EK07-OFF SMK)
|
 |
 |
 |
 |
|
Interface for initial screen
|
Interface for function selection
|
Interface for list of motorbikes
|
 |
 |
 |
|
Interface for list motorbikes
|
Interface for function selection
|
Interface for function selection
|
 |
 |
 |
|
Interface for function selection
|
Read KEYID/ECMID
|
Interface for inactivating key
|
 |
 |
 |
|
Interface for registration key
|
Interface for ECU signal simulation
|
Interface for adjusting ODO
|
